Upgrade CNC MACH3 USB 5 Axis 100KHz USB CNC Smooth Stepper Motion Con

WaveTopSign CNC Mach3 USB 5Axis Stepper Motion Controller

100 left in stock

18.00

DAYS

HRS

MINS

SECS

Variant

Default

PAYMENT ACCEPTED

High quality

In stock

Fast delivery

Details

Description:
It is recommended to use our electronic handwheel or MPG handle to facilitate the connection.
I'm sorry, the slave axis function is not supported. The solution is : Take the Y axis as an example. If the Y axis requires 2 motor drives, you can connect 2 drivers on the Y axis signal interface to control 2 motors.
5-axis mach3 USB controller card, suitable for all versions of mach3 software, support for all versions of Windows operating system, easy to use, very suitable for the users that using mach3 software to make engraving machine.

Features:
1. Support for 5-axis linkage, you can connect four stepper motor drives or servo drives;
2. Maximum step-pulse frequency is 100KHz,which is suitable for the servo or stepping motor;
3. 4 general-purpose opto-couplers isolation input : can connect the limit switch, emergency stop switch, auto tool zero, home switch etc.
4. Support for connecting electronic handwheel;
5. Have 0-10V signal output , you can use mach3 software to control the spindle motor speed.
6. 4 general-purpose isolated relay drive output interface, can drive four relays for controlling the spindle starts, forward rotating and reverse rotating, pumps or other device;
7. 1 status LED, indicate connection status on the board.
