WaveTopSign XC809T 2-6Axis CNC Offline Control System for Lathe
Descriptions:
XC809T multi-function lathe CNC system is a new generation CNC system developed by our company. It adopts a 32-bit high-performance microprocessor, real-time multi-task control technology, and hardware interpolation technology, fully linked high-speed small line segment look-ahead algorithm. 0.001mm interpolation accuracy, maximum speed 30m/min.
XC809T CNC System Hardware and Software Features:
* Based on a 32-bit microprocessor, fully linked, 0.001mm interpolation accuracy, a maximum speed of 30 m / min, support direction + pulse, and quadrature pulse.
* With a 7-inch color widescreen LCD, resolution 800X480, Windows interface style. Equipped with 8 soft function keys, the operation is simple and easy to learn. Provide rich display interface such as parameter classification, alarm log, system diagnosis, etc., convenient for debugging and maintenance.
* International standard G-commands, compatible with FANUC system commands.
* Full-screen editing of the part program, built-in 512M massive program, can store 500 parts program.
* With USB interface, support U disk file reading and writing, data backup.
* Input 24 (expandable to 96) points, output 24 (expandable to 96) points (custom, flexible, and convenient.
* Chinese/English operation interface, complete help information, and more convenient operation.
* Support knife length tool compensation and radius tool compensation.
* Support hand wheel trial processing, convenient program debugging.
* Support multi-level operation rights, convenient device management, and limited-time system locking.
* Support GG, Mastercam, PowerMill, FeatureCAM, and other third-party software G code files.
* Support self-programming tool magazine, flexible use of a variety of tool magazines, servo turrets.
* The two-spindle support spindle 2 synchronizes with the spindle 1 to achieve flying cutter cutting (requires dual servo spindle).
* Dual spindle positioning for double-head machining.
* Simultaneous operation - a feeding program for efficient machining.
* Supports side drilling and tapping spindle 2 position interpolation tapping.
